4in1 light effect with LED matrix, blacklight, RG laser and stroboscope
- 2 laser diodes project hundreds of red and green laser beams
- Laser class 2M: does not require additional protective measures or appointment of a laser safety officer
- Matrix, blacklight, laser and strobe can be controlled individually
- Mains input and output for power linking up to 8 units
- 24 powerful LEDs 0,5 W SMD cold white (CW)
- 2 powerful LEDs 3 W high-power ultra violet (UV)
- 128 powerful LEDs 5 mm R/G/B/W/A
- 14 integrated Showprograms
- Can be operated in 2; 5; 8; 10 CH mode
- The device is cooled by cooling fan
- Controlling by DMX; IR remote control; stand-alone; Sound to light via Microphone; Master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
- Preprogrammed in Light Captain
- Effect: Multi beam effect; flower effect; Strobe effect; UV effect; laser
- With Mounting bracket
- Monochrome 4 digits 7-segment LED display for easy controlling
Package contents
- 1 x Remote control, 1 x Battery, 1 x Device, 1 x User manual, 1 x Power cord
Power supply: | 100-240 V AC, 50/60 Hz |
Power consumption: | 30 W |
IP classification: | IP20 |
Protection class: | Class I |
Power connection: | Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided) |
Power output: | 1 x IEC connector (F) mounting version |
Fuse: | 5 x 20 mm, T 1 A Fuse replaceable |
Lamp type: | LED lamp |
LED: | Strobe effect 24 x 0,5 W SMD cold white (CW) UV effect 2 x 3 W high-power ultra violet (UV) Matrix effect 128 x 5 mm R/G/B/W/A |
Laser class: | Class 2M |
Laser color: | R/G |
Laser module: | Green (G) 30 mW 532nm Red (R) 100 mW 650nm |
DMX channels: | 2; 5; 8; 10 |
DMX input: | 1 x 3-pin XLR (M) mounting version |
DMX output: | 1 x 3-pin XLR (F) mounting version |
Cooling: | Cooling fan |
Control: | DMX; IR remote control; stand-alone; Sound to light via Microphone; Master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional); Light Captain |
Housing color: | Black |
Attachment system: | Mounting bracket |
Display type: | Monochrome 4 digits 7-segment LED display |
Dimensions: | Length: 40,5 cm Depth: 14,5 cm Height: 20,0 cm |
Weight: | 2,85 kg |
Remote control | |
Battery: | 1 x Button cell 3.0 V CR2025 lithium manganese built-in |
