EUROLITE AKKU IP UP-4 Plus HCL Spot WDMX
IP65 uplight with replaceable battery, RGBWA+UV LEDs, WDMX and IR remote control
- Quick and tool-free battery change, additional rechargeable battery optionally available
- Integrated W-DMX transceiver for wireless DMX Control
- Cordless and versatile
- Automatic charging of the battery and status indicator
- Additional frost filter provides a soft, homogeneous light
- Stepless color blend, color change, color fade, dimmer and strobe effect
- Adjustable white balance
- Dimmer speed (step response) adjustable
- Sturdy metal housing with handle and folding foot for angled placement
- Designed for ground use
- Battery operation up to 9,5h depending on program used
- 4 powerful LEDs 10 W high-power 6in1 HCL RGBWA/UV (homogenous color mix)
- 49 integrated Showprograms
- Direct color selection for 63 preset colors
- Can be operated in 6; 8; 12 CH mode
- The device is cooled by passive convection cooling
- Controlling by stand-alone; DMX; W-DMX by wireless solution; Master/slave function; Sound to light via Microphone; IR remote control
- Preprogrammed in Light´J; LED PC-Control 512; LED EASY OPERATOR 4×6; LED EASY OPERATOR DELUXE; Light Captain
- With a beam angle of 16°
- Suitable for outdoor use IP65
- With a KENSINGTON LOCK theft protection
- For application areas such as: Small lender; Wedding/gala/events
Package contents
- 1 x spotlight, 1 x power cord, 1 x external mains adapter, 1 x remote control, 1 x diffusor cover, 2 x screw, 1 x plate, 1 x user manual, 1 x declaration of conformity, 1 x battery, 1 x battery pack
ROADINGER Flightcase 6x AKKU IP UP-4 Plus HCL Spot WDMX with Charging Function
PRO flightcase for 6 x Eurolite AKKU IP UP-4 Plus HCL Spot WDMX with charging function for 8 batteries
- Interior with foam padding
- Aluminum profile frames 25mm with rounded edges
- 4 hinged, chromium plated case handles
- 2 chrome tip-over locks
- 2 high-quality butterfly locks
- 4 castors with 2 locking brakes
- 4 built-in stacking trays in the cover
Package contents
- 1 x case, 1 x power cord, 1 x user manual
Weight: | 49,70 kg |
EUROLITE AKKU IP UP-4 Plus HCL Spot WDMX | |
Power supply: | 100-240 V AC, 50/60 Hz 12,6 V DC 3 A |
Pin configuration: | Inside + outside – |
Power consumption: | 35 W |
IP classification: | IP65 |
Protection class: | Class III |
Power connection: | Mains input via Coaxial power connector (M) power supply cord with AC adapter (provided) Battery/battery pack |
Battery pack type: | 1 x lithium ion 11,1 V, 13000 mAh, 144,3 Wh |
Battery pack: | Tool-free replacement Battery operation up to 9,5h depending on program used Recharging time 8h |
Lamp type: | LED lamp |
LED: | 4 x 10 W high-power 6in1 HCL RGBWA/UV (homogenous color mix) |
DMX channels: | 6; 8; 12 |
Cooling: | Passive convection cooling |
Control: | Stand-alone; DMX; W-DMX by wireless solution; Master/slave function; Sound to light via Microphone; Light´J; LED PC-Control 512; LED EASY OPERATOR 4×6; LED EASY OPERATOR DELUXE; Light Captain; IR remote control |
Beam angle: | 16° |
Beam angle (1/2 peak): | 16° |
Housing color: | Black |
Carrier frequency: | 2,4 GHz |
Theft protection: | KENSINGTON LOCK |
Dimensions: | Width: 17,1 cm Depth: 13,8 cm Height: 20 cm |
Weight: | 4,50 kg |
Noise classification: | Class 0 (no noise at all) |
Remote control | |
Battery: | 1 x Button cell 3.0 V CR2032 lithium manganese built-in |
Legal specifications | |
Special product: | Not designed for household room illumination |
Intended use: | Show effect lighting |
ROADINGER Flightcase 6x AKKU IP UP-4 Plus HCL Spot WDMX with Charging Function | |
Power supply: | 100-240 V AC, 50/60 Hz |
Power connection: | Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided) |
Fuse: | 5 x 20 mm, F 5 A Fuse replaceable |
Status LED: | Charge level |
Aluminum profile frames: | 25 mm |
Case handles: | 4 pc/pcs |
Stop hinge: | 2 pc/pcs |
Lock: | Butterfly lock: 2 pc/pcs |
Transport aid: | 4 x castors with 2 locking brakes 4 x built-in stacking trays in the cover |
Material: | Plywood glued |
Color: | Black, laminated |
Device compartment: | 17,1 cm x 15 cm x 21 cm |
Accessory compartment: | 55,5 cm x 7,8 cm x 21 cm |
Dimensions: | Length: 92,5 cm Width: 48,5 cm Height: 31 cm |
Weight: | 22,70 kg |
