A Power Dynamics mixer and amplifier with 60W RMS output power. Comes with three microphone inputs and a line input. Switchable VOX control and balanced XLR microphone input on channel 1. Channel 3 is switchable between microphone and Auxiliary input. With a 12Vdc connection for external power supply, 100V application, 48V phantom power and bass & treble control.
- VOX Priority on channel 1
- 4 Input channels
- Switchable 48V phantom power
- 100V application
- Switchable Mic / Aux on channel 3
- Peak LEDs
- External 12Vdc connection
Additional Information
Output power:Max. | 70W |
---|---|
Output power: RMS < 2% T.H.D | 60W |
Frequency response | 100Hz – 12kHz ± 3dB |
Signal to noise ratio | >75dB |
Input sensitivity:Mic | 1.5mV |
Input sensitivity:Line | 300mV |
Input sensitivity:Mic 1 | 1.5mV bal. |
Input sensitivity:Mic 2 (unbalanced) | 1.5mV |
Input sensitivity:Mic 3 (unbalanced) | 1.5mV |
Input impedance:Mic | 1.8 Ohm |
Input impedance:Aux/Line | 10kOhm |
Outputs:Speaker | 8 Ohm & 100V |
Power supply | 220-240Vac/50Hz |
Battery | 12Vdc / 5A |
Dimensions | 482 x 88 x 282mm |
Weight | 7.5kg |
