No blood in those veins…
but yet a whole lot of life. A wire diameter of 2 x 0.34 mm² is impressive and the electrical data speaks for itself. A cable giving great performance at an excellent price, used for stage and studio settings.
The large diameter and the low capacity guarantee outstanding transmission quality, even over long distances. The shielding made of polished copper wires is 95 % optically opaque (instead of the usual 85 %).
The robust, rubberlike, matt outer sleeve is preferred by stage musicians and guarantees the highest flexibility even in lowest temperatures.
but yet a whole lot of life. A wire diameter of 2 x 0.34 mm² is impressive and the electrical data speaks for itself. A cable giving great performance at an excellent price, used for stage and studio settings.
The large diameter and the low capacity guarantee outstanding transmission quality, even over long distances. The shielding made of polished copper wires is 95 % optically opaque (instead of the usual 85 %).
The robust, rubberlike, matt outer sleeve is preferred by stage musicians and guarantees the highest flexibility even in lowest temperatures.
Now also available in an FRNC-version!
High quality microphone cable
- High transmission quality due to wide cross-section 2 x 0.34 mm²
- Very low capacity due to pe insulation
- Outstanding shielding due to dense shielding
- Highly flexible
- Application: stage, studio, permanent installation
- Made in Europe
Construction | (2LI2Y0,34mm2)CY |
Jacket, diameter | PVC 6,5 mm |
AWG | 22 |
No. of inner conductors | 2 x 0,34 mm2 |
Copper strand per conductor | 19 x 0,15 mm |
Conductor insulation | PE 1,50 mm |
Shielding | copper braided shielding with 0.10 mm indiv. strand |
Shielding factor | 95 % |
Temperature range | min. -25 °C |
Temperature range | max. 70 °C |
Fire load per m | 0,22 kWh |
Weight per 1 m | 56 g |
Packaging | 100/500 m roll |
Capac. cond./cond. per 1 m | 58 pF |
Capac. cond./shield. per 1 m | 115 pF |
Cond. resistance per 1 km | <55 ohms |
Shield. resistance per 1 km | 25 ohms |
Insulation resist. per 1 km | >1 Gohms |
Surge impedance | approx. 100 ohms |
Cable length: | 100 m |
Color: | Black |
Plug A: | 1 x No connector/cable only |
Plug B: | 1 x No connector/cable only |
