TOPP PRO TP MXI3

PREZZO SU RICHIESTA

?Mixer 3 canali con funzione USB

SPEDIZIONE GRATUITA

per ordini superiori a 200 €

VUOI PAGARE A RATE?
Contatta Paco 329 2237447

EAN: 8032496168447 COD: TP MXI3 Categoria: NO OWN

Descrizione
Informazioni aggiuntive

?Mixer 3 canali con funzione USB

Il mixer TOPP PRO MXI3 è un mixer compatto, portatile e versatile. Risulta pratico e tascabile ma nella sue ridotte dimensione racchiude potenti funzioni.

1 Precision mono input MIC/Line with combojack, Stereo Input
Monitor Output
RCA Tape inputs/outputs
2-band EQ
USB I/O

Frequency Response

Mic Input to any Output	10 Hz to 40 kHz(0, -1dB)
(Gain @ 0 dB, Rated output level)	10 Hz to 400 kHz(0, -3dB)

Distortion (THD&N)

Mic Input to MAIN Output(Gain @ 0 dB, Rated output level @ 20 Hz-20 kHz bandwidth)

0.01% (A-weighted)

MIC EIN (Equivalent Input Noise)

Input: Channel INPUT MIC (Rs = 150 Ohm Gain @ Max.,20 Hz-20 kHz bandwidth)

-118dBu (A-weighted)

CMRR

Mic in to main out(Gain @ Max.,@ 1 kHz)70dB

70dB

Input Gain (20 Hz-20 kHz)

Mono Channel	MIC: 0 to 48dB, LINE: -35 to +15dB
Stereo Channel	—

Attenuation (Crosstalk) (20 Hz-20 kHz)

Line in, 1/4″ TRS Main Out,1 kHz relative to 0 dBu, 22 Hz ~ 22 kHz Filter, Gain @ unity. Main Mix knob/fader @ -8 -79dBu (A-weighted) Channel Level knob/fader @ -8 -79dBu (A-weighted)

Rated Output Level

Main, Aux, Control Room output (all knob/fader @ 0 dBu,1 kHz)

0dBu

Maximum Output Level

Main, Aux, Control Room output (all knob/fader@ 0 dBu,1 kHz, 22 Hz 22 kHz Filter,THD @ 1%)

+17dBu

Maximum Voltage Gain (EQ and PAN/BAL knob@ 0 dB, Other all knob orfader @ max, DFX mute, 1 kHz, Rs=600 Ohm)

Mono Channel MIC INPUT MAIN OUT (3.5mm jack stereo)	69dBu
Mono Channel MIC INPUT Monitor (3.5mm jack stereo)	78dBu
Mono Channel MIC INPUT TAPE OUT (RCA)	69dBu
Mono Channel LINE INPUT MAIN OUT (3.5mm jack stereo)	53dBu
Stereo Channel LINE INPUT MAIN OUT (3.5mm jack stereo)	16dBu
TAPE INPUT MAIN OUT (3.5mm jack stereo)	6dBu
TAPE INPUT Monitor (3.5mm jack stereo)	9dBu

Main mix Noise (20 Hz-20 kHz bandwidth)

MAIN OUT (all knob/fader @ 0 dBu, 22 Hz-22 kHz Filter,Gain @ unity)
Main Mix knob/fader @ -8 ,Channel Level knob/fader @ -8	-120dBu (A-weighted)
Main Mix knob/fader @ 0dB, Channel Level knob/fader @ -8	-100Bu (A-weighted)
Main Mix knob/fader @ 0dB, Channel Level knob/fader @ 0dB	-98dBu (A-weighted)

Equalization

(Mono channels)	Stereo Channels
High +/-15 dB @12 kHz	High +/-15 dB @12 kHz
Low +/-15 dB @80 Hz	Low +/-15 dB @80 Hz

PEAK Indicator

Channel 1

Channel 2

VU Meters

Main Left and Right (1-segment)

Clip +15dBu

Impedance

Microphone Input	2.6k Ohms
Line Input	10k Ohms
Tape Input	10k Ohms
Main Outputs	120 Ohms
Phones Output	120 Ohms
Tape Output	1K Ohms

USB SECTION

USB Interface	USB 2.0 full speed compliant
ADC & DAC	16-Bit Delta-Sigma,44.1kHz Sampling Rates
Operating System	Windows 2000,XP or higher, Mac OS 9.0.4 or higher, 10.Xor higher
